CU251 4 Row Aluminum Radiator for 1960-1966 Ford Falcon Mustang Comet Ranchero, for 1961-1965 Mercury Comet, for 1965-1966 Mustang V8 Gas Radiators Shroud 2 x 12" Fans Thermostat Relay Kit

Fitment:For 1965-1966 Ford Mustang 302-351-390-428-429 EnginesFor 1960-1965 Ford Falcon 302-351-390-428-429 EnginesFor 1960-1965 Ford Ranchero 302-351-390-428-429 EnginesFor 1961-1965 Mercury Comet 302-351-390-428-429 EnginesPackage Include:1 x 4-Row AA5052 Aluminum Radiator1 x CNC Machined Radiator Cap1 x AA5052 Aluminum Shroud1 x 14" Fans (Includes mounting kits)1 x Thermostat Relay KitRadiator DetailsCore Size: 16.46"H x 16.85"W x 2.44"TOverall Size: 21.46"L x 19.69"W x 5.71"HInlet/Outlet: 1.50"/1.77"Transmission oilcooler: φ26*150*1/8NPT(T)Fan Details:Maximum Fan CFM: 2200±200Fan Diameter x Height x Thickness:14.05" x 14.05" x 2.5"Number of Blades: 8 blades (Plastic)Maximum Fan RPM/Amp Draw :2,250 rpm/12.70 ampsRelay Kit Instructions:RED + connect directly to battery.WHITE wire to ignition switch power source.BLACK goes to thermos switch.BLUE wire goes to the Fans.Thermostat Relay Kit:Universal fit for any automotive vehicle and electric fan.Activates by grounding electric fans at preset temperature.180'F turn-on temperature, 165'F turn-off temperature.3/8" NPT thread-in brass probe w/ 1/2" NPT adapter included.Probe typically threads into radiator, water outlet or manifold.Part NumberManufacturer Part Number: CC251, CR251, MC251, CU251, 0251, 433251, A1463Part Number: CU1463, 889251, 8011463, 1463, 251-3OEM Number: 1605-480444, PR0251F APDI 8011463Why Choose us?1.Made of aircraft AA5052 grade aluminum, greatly prolonged the Lifespan!2.Brazed core technology for optimal performance and reliability!3.OEM style brass petcock drain re more durable than other plastic one!4.Meticulously built to superior OE standards for a precise fit!5.Factory direct sales & 3 years warranty! Our goal is meeting your needs!

• 4 Row Core AA5052 Aluminum Radiator for 65-66 Ford Mustang 302-351-390-428-429, for 60-65 Ford Falcon 302-351-390-428-429, for 60-65 Ford Ranchero 302-351-390-428-429, for 61-65 Mercury Comet 302-351-390-428-429, 2.4L 2.8L 4.3L
• Core Size: 16.46" H x 16.85" W x 2.44" T; Overall Size: 21.46" L x 19.69" W x 5.71" H; Inlet/Outlet: 1.50"/1.77"; Transmission oilcooler: φ26*150*1/8NPT(T); Part Number: CC251, CR251, MC251, CU251, 0251, 433251, A1463
• High Performance. Full AA5052 Aircraft Aluminum craftsmanship radiator & exclusive tube design that dramatically increases cooling efficiency by up to 30%~45%, strong and durable, 100% welded by TIG, No Epoxy. 100% Leak Tested
• Easy to Install. Meticulously built to superior OE standards for a precise fit, direct bolt-on replacement. No Drilling or Modifications Needed for Installation
• Crafted by our professional team using the highest-grade materials for exceptional longevity.
